Descrição

Cpu intel® socket lga1200 for 11th gen intel® core processors &
10th gen intel® core – pentium® gold and celeron® processors*
supports up to intel® 65w cpu
supports intel® 14 nm cpu
supports intel® turbo boost technology 2.0 and intel® turbo boost
max technology 3.0**
* refer to www.asus.com for cpu support list.
** intel® turbo boost max technology 3.0 support depends on the
cpu types.
chipset intel® h510 chipset
memory 2 x dimm – max. 64gb – ddr4 3200(oc) – 2933 – 2800 – 2666 – 2400 – 2133
mhz non – ecc – un – buffered memory*
dual channel memory architecture
supports intel® extreme memory profile (xmp)
* 10th gen intel® core i7 – i9 processors support
2933 – 2800 – 2666 – 2400 – 2133 natively – others will run at the maximum transfer
rate of ddr4 2666 mhz.
* 11th gen intel® processors support 2933 – 2800 – 2666 – 2400 – 2133
natively.
* refer to www.asus.com for the memory qvl (qualified vendors
lists) – and memory frequency support depends on the cpu types.
graphics 1 x d – sub
1 x dvi – d
1 x hdmitm 1.4 – 2.0**
* graphics specificatións may vary between cpu types.
** only intel® 11th gen processors support hdmi 2.0 with max.
resolutión of 4k@60hz – others will only support hdmi 1.4 with max.
resolutión of 4k@30hz. please refer to www.intel.com for any updates.
expansión slots intel® 11th & 10th gen processors
1 x pcie 4.0 – 3.0 x16 slot
– intel® 11th gen processors support pcie 4.0 x16 mode
– intel® 10th gen processors support pcie 3.0 x16 mode
intel® h510 chipset
1 x pcie 3.0 x1 slot
storage total supports 4 x sata 6gb – s ports
intel® h510 chipset
4 x sata 6gb – s ports
ethernet 1 x realtek 1gb ethernet
usb rear usb (total 4 ports)
2 x usb 3.2 gen 1 ports (2 x type – a)
2 x usb 2.0 ports (2 x type – a)
front usb (total 6 ports)
1 x usb 3.2 gen 1 header supports additiónal 2 usb 3.2 gen 1 ports
2 x usb 2.0 headers support additiónal 4 usb 2.0 ports
audio pulgadasrealtek alc897 7.1 surround sound high definitión audio
codec* – supports: jack – detectión – multi – streaming – front panel jack –
retasking – supports up to 24 – bit – 192 khz playbackpulgadas
audio features
– audio shielding
– dedicated audio pcb layers
* a chassis with an hd audio module in the front panel is required
to support 7.1 surround sound audio output.
back panel i – o ports 2 x usb 3.2 gen 1 ports (2 x type – a)
2 x usb 2.0 ports (2 x type – a)
1 x d – sub port
1 x dvi – d port
1 x hdmi port
1 x realtek 1gb ethernet port
3 x audio jacks
1 x ps – 2 keyboard (purple) port
1 x ps – 2 mouse (green) port
internal i – o connectors fan and cooling related
1 x 4 – pin cpu fan header
1 x 4 – pin chassis fan header
power related
1 x 24 – pin main power connector
1 x 4 – pin +12v power connector
storage related
4 x sata 6gb – s ports
usb
1 x usb 3.2 gen 1 header supports additiónal 2 usb 3.2 gen 1 ports
2 x usb 2.0 headers support additiónal 4 usb 2.0 ports
miscellaneous
1 x clear cmos header
1 x chassis intrusión header
1 x com port header
1 x front panel audio header (aafp)
1 x lpt header
1 x speaker header
1 x spi tpm header (14 – 1 pin)
1 x 10 – 1 pin system panel header
special features asus 5x protection iii
– digi+ vrm
– languard
– overvoltage protectión
– safeslot core
– stainless – steel back i – o
asus q – design
– q – dimm
– q – slot
asus thermal solutión
– aluminum heatsink design
software features asus exclusive software
armoury crate
ai suite 3
– performance and power saving utility
turbov evo
epu
digi+ vrm
– ez update
asus cpu – z
ai charger
daemon tools
nortón anti – virus software (free trial versión)
winrar
uefi bios
asus ez diy
– asus crashfree bios 3
– asus ez flash 3
– asus uefi bios ez mode
bios 128 mb flash rom – uefi ami bios
manageability wol by pme – pxe
accessories cables
2 x sata 6gb – s cables
miscellaneous
1 x i – o shield
installatión media
1 x support dvd
documentatión
1 x user manual
operating system windows® 10 64 – bit
form factor matx form factor
8.4 inch x 7.4 inch ( 21.3 cm x 18.8 cm )
